BASE

Part No.

Detail

PDF

 2.54

PHC5-H1XX

PHC5-H2XX

Single Row /  Horizonal / SMD Type

Dual Row / Horizonal /  SMD  Type

2.54

PHC5-S1XX

PHC5-S2XX

PHC5-R1XX

PHC5-R2XX

Single Row / Straight  / DIP Type

Dual Row / Straight / DIP  Type

Single Row / Right Angle/ DIP Type

Dual Row / Right Angle / DIP Type

PHC5-M1XX

PHC5-M2XX

Single Row / Striaght / SMD Type

Dual Row / Straight / SMD Type


BASE

Part No.

Detail

PDF

2.00

PHC2-S1XX

PHC2-S2XX

PHC2-R1XX

PHC2-R2XX

Single Row / Straight  / DIP Type

Dual Row / Straight / DIP  Type

Single Row / Right Angle/ DIP Type

Dual Row / Right Angle / DIP Type

2.00

PHC2-M1XX

PHC2-M2XX

Single Row / Striaght / SMD Type

Dual Row / Straight / SMD Type


BASE

Part No.

Detail

PDF

1.50

PHC3-S1XX

PHC3-S2XX

PHC3-R1XX

PHC3-R2XX

Single Row / Straight  / DIP Type

Dual Row / Straight / DIP  Type

Single Row / Right Angle/ DIP Type

Dual Row / Right Angle / DIP Type

1.50

PHC3-M1XX

PHC3-M2XX

Single Row / Striaght / SMD Type

Dual Row / Straight / SMD Type


BASE

Part No.

Detail

PDF

1.00

PHC1-S1XX

PHC1-S2XX

PHC1-R1XX

PHC1-R2XX

Single Row / Straight  / DIP Type

Dual Row / Straight / DIP  Type

Single Row / Right Angle/ DIP Type

Dual Row / Right Angle / DIP Type

1.00

PHC1-M1XX

PHC1-M2XX

Single Row / Striaght / SMD Type

Dual Row / Straight / SMD Type


BASE

Part No.

Detail

PDF

1.70

PHC8-S1XX

PHC8-S2XX

PHC8-R1XX

PHC8-R2XX

Single Row / Straight  / DIP Type

Dual Row / Straight / DIP  Type

Single Row / Right Angle/ DIP Type

Dual Row / Right Angle / DIP Type

1.70

PHC8-M1XX

PHC8-M2XX

Single Row / Striaght / SMD Type

Dual Row / Straight / SMD Type


BASE

Part No.

Detail

PDF

1.00

PHCA-S1XX

PHCA-S2XX

PHCA-M1XX

PHCA-M2XX

Single Row / Straight  / DIP Type

Dual Row / Straight / DIP  Type

Single Row / Straight / SMD Type

Dual Row / Striaght / SMD Type


BASE

Part No.

Detail

PDF

2.54

PHCC-S1XX

PHCC-S2XX

PHCC-M1XX

PHCC-M2XX

Single Row / Straight  / DIP Type

Dual Row / Straight / DIP  Type

Single Row / Straight / SMD Type

Dual Row / Straight / SMD Type


BASE

Part No.

Detail

PDF

1.50

PHCB-S1XX

PHCB-S2XX

PHCB-M1XX

PHCB-M2XX

Single Row / Striaght / DIP Type

Dual Row / Striaght / DIP Type

Single Row / Striaght / SMD Type

Dual Row / Straight / SMD Type


BASE

Part No.

Detail

PDF

2.00

PHCD-S1XX

PHCD-S2XX

PHCD-M1XX

PHCD-M2XX

Single Row / Straight  / DIP Type

Dual Row / Straight / DIP  Type

Single Row / Straight / SMD Type

Dual Row / Straight / SMD Type
